| 모듈타입 | JKM320PP-72 | JKM325PP-72 | JKM330PP-72 | JKM335PP-72 | JKM340PP-72 | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| STC | NOTC | STC | NOTC | STC | NOTC | STC | NOTC | STC | NOTC | |
| 최대출력(Pmax) | 320Wp | 238Wp | 325Wp | 242Wp | 330Wp | 246Wp | 335Wp | 250Wp | 340Wp | 245Wp |
| 최대전압(Vmp) | 37.4V | 34.7V | 37.6V | 35.0V | 37.8V | 35.3V | 38.0V | 35.6V | 38.2V | 35.9V |
| 최대전류(Imp) | 8.56A | 6.86A | 8.66A | 6.91A | 8.74A | 6.97A | 8.82A | 7.02A | 8.91A | 7.08A |
| 개방전압(Voc) | 46.4V | 43.7V | 46.7V | 44.0V | 46.9V | 44.2V | 47.2V | 44.4V | 47.5V | 44.6V |
| 단락전류(Isc) | 9.05A | 7.30A | 9.10A | 7.34A | 9.14A | 7.38A | 9.18A | 7.43A | 9.22A | 7.47A |
| 모듈효율(%) | 15.98% | 16.75% | 17.01% | 17.56% | 17.52% | |||||
인증서
